The ultimate multi-performer, offering the joy of tactile control and the versatility to adapt to anything from circuits to winding roads.
- In line with the increased body rigidity resulting from the minor change, the damping characteristics have been revised to achieve smooth characteristics even at the limit while pursuing responsiveness.
- The rear spring rate has been increased compared to the previous model, providing high roll rigidity and stability for circuit driving with high-grip tires, and tuning has been carried out to allow the driver to step on the accelerator more boldly even in high-speed corners.
- With the possibility of driving to and from the circuit in mind, we paid particular attention to adjusting the damping force to SOFT so that high-rate jolts and vibrations can be suppressed.
- We tested the car on the main course of Fuji Speedway with ADVAN A052 265/35-18 tires. Good results were obtained with a front camber of -4°40', front and rear toe out of 1.9mm, and damping force settings of 7 positions for the front and 6 positions for the rear. Please use this as a reference when adjusting your settings.
Specifications
| FRONT | REAR | |
|---|---|---|
| Damping force adjustment | 30 steps | 30 steps |
| Base valve | - | - |
| Full length adjustment | 〇 | 〇 |
| Upper Mount | Piro | Piro |
| Inverted/Upright | Handstand | upright |
| Damper/spring configuration | Integrated type | Separate type |
| Spring rate changed at time of shipment | Possible | Possible |
| Damping force adjustment with wire | - | - |
|
Helper spring (spring rate N/mm) |
Yes (19.8) | Yes (19.8) |
Vehicle height information (mm)
| At time of shipment*2 | During testing | Maximum upper limit to maximum lower limit*3 | Upper limit of drivable range - Lower limit of drivable range*4 | ||
|---|---|---|---|---|---|
| FRONT | Vehicle height*1 | 657 | 641 | 681 to 627 | 681 to 627 |
| Normal ratio | -twenty four | -40 | 0 to -54 | 0 to -54 | |
| REAR | Vehicle height*1 | 656 | 642 | 677 to 606 | 677 to 606 |
| Normal ratio | -twenty one | -35 | 0 to -71 | 0 to -71 | |
*Not compatible with HIPERMAX R (80310-AT005) for the early model (up to March 2024).
